Use in multiple areas: Purifying laminar flow operating room, mainly applicable to surgeries.
Color temperature adjusted: Through reliable beam synthesis control technology, the color temperature can be adjusted between 3800K-5000K under the condition of ensuring the color rendering index of 93. Achieve ideal tissue contrast and resolution.
Illumination adjustable: The illuminance is 120,000-160,000Lux. 8 different illumination modes to adjust. Useful to many different surgery needs.
High quality material selection: The balance arm is an imported arm, very durable.The lamp cap shell is made of aluminum alloy with good heat dissipation performance.
Removeable handles: Easy to remove and sterilize for reuse. Controls the direction and depth of the light.
long bulb life: All made of German Osram, more than 10 years using life.
Multiple control panels to choose from: A number of functions can be adjusted, easy to use.
Endoscope adjustable: Quickly switch from the general lighting mode, Does not interfere with the physician's career and observation of the tissue during endoscopic surgery.
Low energy consumption: The power consumption of our lamp head only needs 80w+60w.
Good shadowless effect: Each bulb in each group has no gaps and each bulb is independent.
Specification:
|
Technical Parameters |
700mm head / 500mm head |
|
Illuminance (Lux) |
≥160,000lux / ≥140,000lux |
|
Color temperature |
3800±500K, 4400±500K, 5000±500K |
|
Ultraviolet light irradiance within40nm wave |
0.3W/M2, 0.4W/M2 |
|
50% Spot Diameter (D50) |
55% / 51% |
|
10% Spot Diameter (D10) |
291mm / 268mm |
|
Depth Of Illuminance |
1400mm |
|
The adjusting range of Illumination % |
25~100% |
|
Light Focus adjustment System |
Manual |
|
Terperature at surgeon's head |
≤ 1°C |
|
CRI RA |
95 |
|
Total Power Consumption |
80W/60W |
|
Service life of illuminant |
50,000h |
|
Battery |
optional |
|
Total irradiance |
544W/㎡ 534W/㎡ |
|
Size og light field |
240-300mm |
|
Power supply voltage |
AC110-240V 50/60Hz |
|
Best height of installation |
2900mm |
|
Total LED bulb quantity |
108pcs/72pcs |
