The medical vacuum systems are designed to operate according to FDA, CE, BS HTM 2022, EN 737-3 and ISO 7396-1 standards.
All systems could be constructed in compact or not set up.
The vacuum plant design enables isolation of each component without interrupting the overall system operation.
The medical vacuum systems are designed to operate according to FDA, CE, BS HTM 2022, EN 737-3 and ISO 7396-1 standards.
All systems could be constructed in compact or not set up.
The vacuum plant design enables isolation of each component without interrupting the overall system operation.
The vacuum central system usually incorporates the following elements:
Oil-free or oil bath scroll pumps can be selected, Capacity range: 0,5 - 20KW
- Vessel (Painted / Galvanised). Capacity range:500-5.000lt
- Filters
- Electronic and remote control panel
|
|
SINGLE FLOW |
POWER (kw) |
SYSTEM FLOW |
OVERALL DIMENSIONS |
WEIGHT |
||||
|
(L*W*H)mm |
(kg) |
||||||||
|
TWO-PUMPS |
|||||||||
|
GVN1.511 |
62 |
1.5 |
124 |
1820*850*1300 |
270 |
||||
|
GVN2.211 |
100 |
2.2 |
200 |
1820*850*1300 |
310 |
||||
|
GVN2.7l1 |
120 |
2.7 |
240 |
1820*850*1300 |
340 |
||||
|
GVN3.0I1 |
150 |
3.0 |
300 |
1820*850*1300 |
360 |
||||
|
GVN4.0I1 |
215 |
4.0 |
430 |
1600*1200*1850 |
450 |
||||
|
GVN5.5I1 |
300 |
5.0 |
600 |
1600*1350*1850 |
490 |
||||
|
GVN9.0I1 |
400 |
9.0 |
800 |
2700*1400*1850 |
870 |
||||
|
GVN11.01ll |
500 |
11.0 |
1000 |
2700*1400*1850 |
1050 |
||||
|
THREE-PUMPS |
|||||||||
|
GVN1.5III |
60 |
1.5 |
180 |
2400*1200*1850 |
330 |
||||
|
GVN2.2I1I |
100 |
2.2 |
300 |
2400*1200*1850 |
390 |
||||
|
GVN2.7III |
120 |
2.7 |
360 |
2400*1200*1850 |
440 |
||||
|
GVN3.0III |
150 |
3.0 |
450 |
2400*1200*1850 |
460 |
||||
|
GVN4.0III |
211 |
4.0 |
633 |
2400*1350*1850 |
530 |
||||
|
GVN5.5IlI |
300 |
5.5 |
900 |
2400*1350*1850 |
610 |
||||
|
GVN9.0III |
400 |
9.0 |
1200 |
3300*1400*1850 |
1150 |
||||
|
GVN11.0III |
500 |
11.0 |
1500 |
3300*1400*1850 |
1350 |
||||
